Panasonic TH-42PX60U

16.3. Electrical Replacement Parts
List (TH-42PX60U)
Note:
All parts except parts mentioned [PAVCA] in the Remarks
column are supplied by PAVC-CSG.
Parts mentioned [PAVCA] are supplied by PAVCA.
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
F401.40
2
K5D802BNA005 TIME LAG FUSE HIGH 2
C11 K1MN55BA0076 55P CONNECTOR 1
C12 K1MN20BA0231 20P CONNECTOR 1
C21 K1MN55BA0076 55P CONNECTOR 1
C22 K1MN20BA0231 20P CONNECTOR 1
C23 K1KA12BA0107 12P CONNECTOR 1
C402 F1J1C1050011 C 1UF, Z, 50V 1
C404 F0CAF105A021 C 1UF, 250V 1
C407 EEUEB2W220B E 22UF, 450V 1
C408 ECJ2XB1H102K C 1000PF, K, 50V 1
C409 F0CAF225A021 C 22UF, 250V 1
C410 ECJ2XB1H103K C 0.01UF, K, 50V 1
C413 ECJ2XB1H104K C 0.1UF, K, 50V 1
C414 ECQU2A473ML P 0.047UF, M,250V 1
C421 F1J1C1050011 C 1UF, Z, 50V 1
C422 ECJ2XB1H103K C 0.01UF, K, 50V 1
C423 ECJ2XB1H472K C 4700PF, K, 50V 1
C425 ECJ2XB1H103K C 0.01UF, K, 50V 1
C426 ECJ2XC1H471J C 470PF, J, 50V 1
C427 F1J1C1050011 C 1UF, Z, 50V 1
C428 ECJ2XC1H221J C 220PF, J, 50V 1
C429 F1E2J4730001 C 0.047PF, , 600V 1
C431 ECJ2XB1H102K C 1000PF, K, 50V 1
C432 F1J1C1050011 C 1UF, Z, 50V 1
C433 ECJ3XB1E104K C 0.1UF, K, 25V 1
C434 F1J1C1050011 C 1UF, Z, 50V 1
C436 F1J1C1050011 C 1UF, Z, 50V 1
C440 ECA1HM100 E 10UF, 50V 1
C443,44 F1A3A102A040 C 1000PF, J, 1KV 2
C445 F1J1C1050011 C 1UF, Z, 50V 1
C446,47 F2B2W2010001 C 200UF, 450V 2
C450 ECJ2XB1H103K C 0.01UF, K, 50V 1
C451 F1A3A101A040 C 100PF, J, 1KV 1
C457 ECWH12333RHV P 0.013UF,J,1.2KV 1
C460,61 F1A3A331A039 E 330UF, 1KV 2
C462 ECJ3YB1E105K C 1UF, K, 25V 1
C463 ECJ2XC1H220J C 22UF, J, 50V 1
C467 ECKCNA221KB7 C 220PF, M, 1
C468 ECJ2XB1H103K C 0.01UF, K, 50V 1
C469 ECKCNA221KB7 C 220PF, M, 1
C470 F0CAF105A021 C 1UF, 250V 1
C473,74 ECKCNA101KB7 C 100PF 2
C476 ECKCNA101KB7 C 100PF 1
C478 ECKCNA101KB7 C 100PF 1
C493 ECA1HM470 E 47UF, 50V 1
C494 F2A2E1R00008 E 1.0UF, 250V 1
C497 ECA1HM470 E 47UF, 50V 1
C501,02 ECJ2XB1H103K C 0.01UF, K, 50V 2
C503 ECJ2XC1H471J C 470PF, J, 50V 1
C504 F1J1C1050011 C 1UF, Z, 50V 1
C505 ECJ2XB1H102K C 1000PF, K, 50V 1
C506,07 ECJ2XB1H103K C 0.01UF, K, 50V 2
C508 ECJ2XC1H471J C 470PF, J, 50V 1
C509 ECA1EHG101 E 100UF, 25V 1
C510 ECJ2XB1H104K C 0.1UF, K, 50V 1
C511 ECJ2XB1H102K C 1000PF, K, 50V 1
C512-14 ECJ2XC1H471J C 470PF, J, 50V 3
C515 F2A1A1220011 E 1200UF, 10V 1
C516 ECJ2XB1C474K C 0.47UF, Z, 16V 1
C517 F2A1E221A096 E 220UF, 25V 1
C518 ECJ2XB1H104K C 0.1UF, K, 50V 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C519 F1J1C1050011 C 1UF, Z, 50V 1
C520 ECWH8683RHV P 0.068PF, J, 8KV 1
C523 ECJ3YB1E105K C 1UF, K, 25V 1
C526 ECJ2XB1H223K C 0.022UF, K, 50V 1
C527 ECJ3YB1E475K C 4.7UF, K, 25V 1
C528,29 F1J1C1050011 C 1UF, Z, 50V 2
C530 ECJ2VB1H333K C 0.033UF, K, 50V 1
C531 ECJ3YB1E105K C 1UF, K, 25V 1
C533 ECJ2XB1H103K C 0.01UF, K, 50V 1
C534 ECJ2XC1H471J C 470PF, J, 50V 1
C546,47 ECJ2XB1H102K C 1000PF, K, 50V 2
C550 ECJ2XC1H331J C 330PF, J, 50V 1
C551,52 ECJ2XB1H104K C 0.1UF, K, 50V 2
C554 F1J1C1050011 C 1UF, Z, 50V 1
C555 F2A2C471A119 E 470UF, 160V 1
C556,57 EEUFC1E152 E 1500UF, 25V 2
C558 F2A1E471A096 E 470UF, 25V 1
C559 F2A1A1220011 E 1200UF, 10V 1
C562 ECJ2XB1H223K C 0.022UF, K, 50V 1
C571 ECJ2XC1H330J C33PF,J,50V 1
C574 ECJ2XB1H104K C 0.1UF, K, 50V 1
C577 F2A2A330A022 E 33UF, 100V 1
C581 ECJ2XB1H223K C 0.022UF, K, 50V 1
C583 ECJ2XB1H102K C 1000PF, K, 50V 1
C584,85 ECJ2XB1H223K C 0.022UF, K, 50V 2
C587 ECJ2XB1H332K C 3300PF, K, 50V 1
C601 ECJ2XB1H103K C 0.01UF, K, 50V 1
C603 ECJ2FB1E105K C 1UF, K, 25V 1
C604,05 F2A2D1510008 E 150UF, 200V 2
C607 F1J1C1050011 C 1UF, Z, 50V 1
C608 ECJ2XB1H103K C 0.01UF, K, 50V 1
C610 F1J1C1050011 C 1UF, Z, 50V 1
C611 F2B2T1420003 E 1400UF, 220V 1
C612,13 ECJ2XB1H103K C 0.01UF, K, 50V 2
C615 F2B2T1420003 E 1400UF, 220V 1
C616 F1A3A102A040 C 1000PF, J, 1KV 1
C619 ECJ2XB1H104K C 0.1UF, K, 50V 1
C620 ECJ2XB1H103K C 0.01UF, K, 50V 1
C623 ECA1HM100 E 10UF, 50V 1
C624 ECJ2XB1H103K C 0.01UF, K, 50V 1
C625 ECA1HM100 E 10UF, 50V 1
C626 ECJ2XB1H103K C 0.01UF, K, 50V 1
C627 ECJ2XB1H102K C 1000PF, K, 50V 1
C629-31 ECJ2XB1H103K C 0.01UF, K, 50V 3
C632 ECJ2XC1H331J C 330PF, J, 50V 1
C634 ECJ2XB1H102K C 1000PF, K, 50V 1
C635 ECJ2XB1H103K C 0.01UF, K, 50V 1
C638,39 ECJ2XB1H103K C 0.01UF, K, 50V 2
C640 ECJ2XB1H104K C 0.1UF, K, 50V 1
C641 ECJ2XB1H102K C 1000PF, K, 50V 1
C643 ECA1HM470 E 47UF, 50V 1
C650 ECJ2XB1H104K C 0.1UF, K, 50V 1
C653 ECJ2XB1H102K C 1000PF, K, 50V 1
C654 ECJ3YB1E105K C 1UF, K, 25V 1
C655,56 ECJ3YB1E225K C 2.2UF, K, 25V 2
C657 ECJ2XB1H102K C 1000PF, K, 50V 1
C658 ECJ3YB1E105K C 1UF, K, 25V 1
C659 ECJ2XB1H103K C 0.01UF, K, 50V 1
C660 ECJ2FB1C225K C22UF,K,16V 1
C661,62 ECJ2XB1H103K C 0.01UF, K, 50V 2
C1106 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C1111 ECJ0EB1A104K C 0.1UF, K, 10V 1
C1116 ECJ0EB1A104K C 0.1UF, K, 10V 1
C1118-
23
ECJ0EB1A104K C 0.1UF, K, 10V 6
C1125 ECJ0EB1A104K C 0.1UF, K, 10V 1
C1127-
32
ECJ0EB1A104K C 0.1UF, K, 10V 6
C1133,3
4
ECJ1XC1H150J C15PF,J,50V 2
C1135-
42
ECJ0EB1A104K C 0.1UF, K, 10V 8
C1144-
50
ECJ0EB1A104K C 0.1UF, K, 10V 7
183
TH-37PX60U / TH-42PX60U
