Panasonic VL-MV26 Installation Guide

104
9
Appendix
Power Supply Unit
Power
source
Power
supply unit (VL-PS240)
24
V DC, 0.1 A
Power
consumption
(Distribution
mode) Standby: Approx.1.2 W,
During operation: Approx.2.0 W
(
Repeater mode) Standby: Approx.1.6 W
During operation: Approx.1.8 W
Dimensions
(H x W x D)
(Excluding protruding sections)
108.5 x 210 x 52.5 mm
Weight
400 g
Operating
environment
Ambient
temperature: Approx. -10 °C to +50 °C
Relative
humidity (non-condensing): up to 90 %
(indoor
use only)
Installation
method
Wall mount or attach to DIN rail
External
material
ABS (flame retardant ABS resin)
Supported
functions
Dip
switch
• Mode change (Distribution mode / Repeater mode)
• Termination setting (Normal/Terminal)
• ID setting (1-7 by binary number)
10-4. Distribution Box : VL-V701 (Specifications)
