Panasonic VL-MV26 - Lift Controller Settings (Relay Control)

Control Box
Lift Controller
Lift-1
99F
:
89F
:
80F
19 F
:
9 F
:
0 F
59 F
:
49 F
:
40 F
79 F
:
69 F
:
60 F
39 F
:
29 F
:
20 F
#05
#04
#03
#02
#01
Lift-3
99F
:
89F
:
80F
19 F
:
9 F
:
0 F
59 F
:
49 F
:
40 F
79 F
:
69 F
:
60 F
39 F
:
29 F
:
20 F
#05
#04
#03
#02
#01
Lobby Station
Lift-2
99F
:
89F
:
80F
19 F
:
9 F
:
0 F
59 F
:
49 F
:
40 F
79 F
:
69 F
:
60 F
39 F
:
29 F
:
20 F
#05
#04
#03
#02
#01
Lift Controller
Lift Controller
3
Wiring
3-10. Lift Controller settings (Relay control)
Up to 3 Lift
3 branches x 5 lift controllers Up to 100 floor per lift (Up to 20 floor per lift controller)
38
Port of Lift Controller
1 2 3 4 5 6 7 8 9 10
Floor 11 12 13 14 15 16 17 18 19 20
19 F 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 1
:
:
10 F 0 0 0 0 0 0 0 0 0 0
1 0 0 0 0 0 0 0 0 0
9 F 0 0 0 0 0 0 0 0 0 1
0 0 0 0 0 0 0 0 0 0
8 F 0 0 0 0 0 0 0 0 1 0
0 0 0 0 0 0 0 0 0 0
7 F 0 0 0 0 0 0 0 1 0 0
0 0 0 0 0 0 0 0 0 0
6 F 0 0 0 0 0 0 1 0 0 0
0 0 0 0 0 0 0 0 0 0
5 F 0 0 0 0 0 1 0 0 0 0
0 0 0 0 0 0 0 0 0 0
4 F 0 0 0 0 1 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0
3 F 0 0 0 1 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0
2 F 0 0 1 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0
1 F 0 1 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0
G 1 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0
