Panasonic VL-MV26 Installation Guide

4-4. Access Control & E-Lock configuration
51
4
Integration
Electrical
Lock
Access Control & E-Lock
Access Control
/Card Reader
(Outside)
2 (N/P)
Electrical
Lock
Access Control, E-Lock & Lobby Station
Access Control
/Card Reader
(Outside)
2 (N/P)
K-OUT
K-IN
2 (N/P)
E-Lock & Lobby Station
K-OUT
K-IN
DOOR
EXIT
OR
Poewe
r
supply
12 V DC
K-OUT K-IN
N/
P
N/
P
N/
P
POWER SUPPLY
UNIT
VL-
V900
Switch
(Inside)
Switch
(Inside)
Setting by Setup Tool
K-IN and K-OUT(EXTERNAL)signal
OPEN : Normally CLOSE Active OPEN
CLOSE : Normally Open Active CLOSE
KEY OPEN TIME
KEY OUT SIGNAL active time : 0 – 20 s
