5-2-1. How to Setup
5
Setup Tool
57
<Situation1> If you know where the cable connect to.
1. Programing the setup tool based on the
drawing.
2. Wiring Lobby and Control Box
Connect the PC vis USB and upload the date
to the Control Box and Lobby from setup tool.
Control Box
VL-V700
Lobby Station
VL-V900
3. Wiring all monitors based on the drawing
and upload (set) the date from tool.
4. Calling from Lobby to each room and
check the audio and video quality.
No. 301
Drawing
Programing date should be back up by the Installer or Dealer.
To Next Page
