Panasonic WV-CW590G

14
Pan/tilt settings
n Using the Pan/Tilt Setup Menu
Display the pan/tilt setup menu from the setup menu to
configure pan and tilt settings.
First,displaythepan/tiltsetupmenu.
1. Display theadvanced setupmenu (page8), move
thecursortoPAN/TILT
, and then press the CAM
(SET)button.
This will display the pan/tilt setup menu.
* The following sections numbered 1 to D explain
how to use each of the pan/tilt setup menu items.
1 Position Number Selection (PRESET)
Positions can be assigned numbers, each of which can
be configured with a monitoring positi on and
monitoring conditions.
You can use either the PRESET item or the MAP item on
the pan/tilt setup menu to select a position number.
Position numbers 1 through 4 are used for alarm
functions(pages23and24)andoperatingthem.
1. Move the cursortothe 1 next tothePRESET item,
and then tilt the joystick left or right to change the
position number to the one you want.
2. PresstheCAM(SET)button.
This registers the position number setting and
displaysthepresetsettingmenu(thispage).
2 Position Number Selection (MAP)
You could use the MAP item on the pan/tilt setup menu
instead of the PRESET item to select a position number.
1. Move the cursor to MAP
, and then press the
CAM(SET)button.
2. Move the cursor to the number you want to select,
andthenpresstheCAM(SET)button.
This registers the position number setting and
displaysthepresetsettingmenu.(thispage)
To select a position number in the range of 033 to
064, move the cursor to 33-64 in the lower left corner
ofthemenu,andthen presstheCAM(SET)button.
Preset numbers set subsequently are the same.
l Position Setting (POSITION SET)
See pages 6 and 7 for information on the setting
method.
l Adjusting Camera Position When
Changing Cameras (PAN OFFSET SET)
See page 7 for information on the setting method.
l Preset ID Setting (PRESET ID)
See pages 7 and 8 for information on the setting
method.
l Light Control (ALC/MANUAL)
See pages 9 and 10 for information on the setting
method.
You can adjust the lens iris setting on the detailed
menuwhenMANUALisset.
**PAN/TILT SETUP**1/2
PRESET 1
MAP
HOME POSITION OFF
SELF RETURN OFF
AUTO MODE OFF
AUTOPAN KEY AUTOPAN
PATROL
PRIVACY ZONE OFF
IMAGE HOLD OFF
DIGITAL FLIP ON
PROPO.P/T ON
1
3
5
7
9
A
2
4
6
8
>
**PAN/TILT SETUP**2/2
AREA TITLE OFF
TILT ANGLE 0˚
CLEANING OFF
RET TOP
B
C
D
**PRESET POSITION**
2
6
10
14
18
22
26
30
1*
5
9
13
17
21
25
29
ID:
033-064 225-256
RET TOP
3
7
11
15
19
23
27
31
4
8
12
16
20
24
28
32
**PRESET POSITION**
34
38
42
46
50
54
58
62
33
37
41
45
49
53
57
61
ID:
065-096 001-032
RET TOP
35
39
43
47
51
55
59
63
36
40
44
48
52
56
60
64
PRESET NO. 1*
POSITION SET
PRESET ID
ALC/MANUAL
AF MODE
DWELL TIME
SCENE FILE
PRESET SPEED
RET TOP DEL
ON
ALC
MANUAL L
10S
OFF
••••••I255
L H
Notes:
•An asterisk (*) to the right of a position number
indicates that it already has a preset position
assigned to it.
The home position number is indicated by the letter
Hnexttotheasterisk(*).
•When the cursor is located at a position number
thathasapositionID,thepositionIDtextappears
nexttoID:onthemenuscreen.
