Panduit PanTher LS8 User Manual

LOADING BATTERIES AND LABEL CASSETTE
10
Loading the Batteries
1. Remove the battery door from the back of the PANTHER LS8 printer. If
the impact bumper is installed on the printer, you will have to move it
away from the battery door first.
2. Install the 6 AA batteries according to the molded indicators within the
battery compartment.
3. Reattach the battery door. Move the impact bumper back over the battery
door if necessary.
Loading a Label Cassette
1. Remove the cassette door from the back of the PANTHER LS8 printer.
2. Remove the plastic sleeve from the cassette. Retain the sleeve for later
use.
3. Install a label cassette. Press firmly to lock the cassette in place.
4. Lock the drive roller.
5. Reattach the cassette door.
NOTE: To uninstall a label cassette:
1. Unlock the drive roller.
2. Remove the cassette door.
3. Remove the cassette. Use the removal tab for
assistance.
4. Re-apply the plastic sleeve to the cassette.
5. Reattach the cassette door.

Panduit PanTher LS8 Specifications

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)
operating temperature	41-104° F (5-40 °C)

Weight and Dimensions

weight	1.8 lbs. (1.86 kg)
effective print width	1.00” (25.4 mm)
print length	30.00” (maximum label length)
