USING THE PANTHER ™ LS8
14
The Home Screen
The home screen is where the user enters and edits text or places label items
known as tools. The home screen is also where the user prints labels. The
home screen has several different indicators, including:
INDICATOR ICON DESCRIPTION
Caps Lock Indicates if caps lock is on or off.
Shift Function
or
Indicates if the shift key has been pressed.
Text Size Indicates the text size for the current line.
Text Style B
B
Indicates the text style for the current
cursor position. Available styles include
Bold and Bold + Underline.
Text Line Indicates the current line.
Page
1:9
Indicates the current page. There are 9
total pages.
Vertical or
Horizontal Line
Indicates that a label has one or more
dividing lines selected.
Frame Indicates that a label has a frame selected.
The Tool Menu
The tool menu includes serializations, symbols, data lists, bar codes, and
date/time stamps. These items are placed on the home screen. The tool
menu is accessed by pressing the Insert key.
Tool Icons
The following icons represent the available tools:
- Serialization
- Symbol
- Data List
- Barcode
- Date Stamp
- Time Stamp

Panduit PanTher LS8 Specifications

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)
operating temperature	41-104° F (5-40 °C)

Weight and Dimensions

weight	1.8 lbs. (1.86 kg)
effective print width	1.00” (25.4 mm)
print length	30.00” (maximum label length)
