CREATING SYMBOLS
20
The Symbol Tool
The Symbol Tool is used for creating electrical, network, and safety or facility
identification labels.
Creating a Symbol
The symbol tool should be accessed from the home screen. To access the
symbol tool:
1. Press the INSERT key to enter the tools menu.
2. Press the directional arrows to highlight the symbol tool.
3. Press the key to select the symbol tool.
4. Use the right or left directional arrow keys to search the symbol library.
(see the next page for available symbols
5. Use the up or down directional arrow keys to increase or decrease the
size of the symbol.
6. Press the key to accept the changes and to return to the home
screen. Otherwise, press the DEL key to return to the home screen
without accepting changes.
7. On the home screen, the symbol tool icon will appear at the position
of the cursor.
Editing a Symbol
To edit a symbol on the home screen, move the cursor directly to the left of
the symbol and then press the INSERT key.
1. Use the right or left directional arrow keys to search the symbol library.
(see the next page for available symbols
2. Use the up or down directional arrow keys to increase or decrease the
size of the symbol.
3. Press the key to accept the changes and to return to the home
screen. Otherwise, press the DEL key to return to the home screen
without accepting changes.
NOTE: There are 3 sizes available for each symbol. The sizes range from 1
(smallest) to 3 (largest).

Panduit PanTher LS8 Specifications

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)
operating temperature	41-104° F (5-40 °C)

Weight and Dimensions

weight	1.8 lbs. (1.86 kg)
effective print width	1.00” (25.4 mm)
print length	30.00” (maximum label length)
