CREATING SERIALIZATIONS
19
To change the Collate parameter, press the up or down directional
arrow keys to highlight Collate.
Press the right directional arrow key to select Yes or No.
Press the key to accept the changes and to return to the home
screen.
Advanced Serialization Options
The serialization tool includes several advanced options for customizing
labels. The advanced serialization options are Print As and Place On.
1. The Print As option determines whether the serialization will print as text
or as a bar code on the labels. The default setting will print as text. The
bar code settings can be changed in the setup menu. Printing a
serialization as a bar code is useful for asset tracking, component
manufacturing, and quality control.
2. The Place On option determines whether the serialization will print on
consecutive labels or on consecutive pages of the same label. The
default setting will print on labels. Printing a serialization on pages is
useful for creating serialized patch panel labels using die cut network
systems label media.
Editing a Serialization
To edit a serialization on the home screen, move the cursor directly to the left
of the serialization and then press the INSERT key. Follow the steps listed
above for creating a serialization.

Panduit PanTher LS8 Specifications

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)
operating temperature	41-104° F (5-40 °C)

Weight and Dimensions

weight	1.8 lbs. (1.86 kg)
effective print width	1.00” (25.4 mm)
print length	30.00” (maximum label length)
