SETTING UP THE PANTHER LS8
AND USING FILE MANAGER
The Setup Menu
The setup menu is used to modify the default printer settings. The setup
menu should be accessed from the home screen. To access the setup menu
press the key.
Use the setup menu to adjust the contrast, heat, time, date, units, language,
and bar code settings. Also use the setup menu to transfer files to a personal
computer or to upgrade your printer’s operating system.
Within the setup menu, scroll up or down using the directional arrows. Select
the setting to adjust by pressing ENTER. Once inside the setting, use the
arrow to select a parameter to change. Press ENTER to accept the changes
and return to the main setup menu screen.
Press SETUP to exit from the setup menu will all changes.
Label Modes
To edit the label mode, press the LABEL key.
1. Use the up or down directional arrows to select the desired mode and
press ENTER.
Available Modes include:
MODE DESCRIPTION APPLICATIONS
Component Vertically centers legend Electrical components
Wiremarker Repeats legend until label is filled Wire and cable marking
Terminal Places legends at terminal
locations
Terminal blocks
Tape Rotates legends 90° clockwise Safety/facility ID, pipe
marking
Strip Repeats legend until label is filled
and copies legend on two sides of
middle perforation
Wire and cable marking
Network Places legends at port locations Data communications
components
Flag Prints legend once at top of label
and then repeats the legend once
at the bottom of label
Wire and cable marking
Vertical Prints legend vertically Safety/facility ID, pipe
marking
