Panduit PanTher LS8 User Manual

CREATING A DATE OR TIME STAMP
AND CREATING LINES
27
6. The Right setting places a line at the far right side of the label.
7. The @ Pages setting places lines between each page of a label that has
multiple pages defined. The @ Pages setting is used for patch panel,
outlet, and terminal block labeling.
Creating Lines
Lines should be accessed from the home screen. To access the line tool:
1. Press the LINE key.
2. Use the up or down directional arrow keys to select the desired line
position.
3. Use the right or left directional arrow keys to turn on or turn off the line
tool at the selected position.
4. Press the key to accept the changes and to return to the home
screen. Otherwise, press the DEL key to return to the home screen
without accepting changes.
5. On the home screen, the line icon will appear on the right side of the
display when a line is activated.
A01
A01 A02 A03 A04 A05 A06

Panduit PanTher LS8 Specifications

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)
operating temperature	41-104° F (5-40 °C)

Weight and Dimensions

weight	1.8 lbs. (1.86 kg)
effective print width	1.00” (25.4 mm)
print length	30.00” (maximum label length)
