CREATING A DATE OR TIME STAMP
AND CREATING LINES
26
Lines
Lines allows custom placement of vertical and horizontal lines on a label.
Lines are especially useful for creating patch panel, faceplate, or terminal
block labels. There are seven unique line settings available: Center
Horizontal, Center Vertical, Top, Bottom, Left, Right, and @ Pages. Each
of these settings may be turned on or off independently.
NOTE: The top, bottom, left, and right sides of the label will rotate
with the legend when a label is rotated.
1. The Center Horizontal setting places a line through the center of the
label in the horizontal direction.
2. The Center Vertical setting places a line through the center of the label
in the vertical direction.
3. The Top setting places a line at the top of the label.
4. The Bottom setting places a line at the bottom of the label.
5. The Left setting places a line at the far left side of the label.
A01
A02
A01 A02
A01
A01
A01

Panduit PanTher LS8 Specifications

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)
operating temperature	41-104° F (5-40 °C)

Weight and Dimensions

weight	1.8 lbs. (1.86 kg)
effective print width	1.00” (25.4 mm)
print length	30.00” (maximum label length)
