PRINTER CLEANING INSTRUCTIONS
33
Cleaning the Print Head and Drive Roller
The print head should be cleaned regularly, and more often in harsh
environments. The drive roller should be cleaned whenever foreign matter,
such as dust or adhesive, is present.
1. Turn OFF power to printer.
2. Unlock the drive roller lever.
3. Remove the label cassette from the printer
4. Use a cotton swab and rubbing alcohol to gently wipe the print head, drive
roller, and cutter blade.

Panduit PanTher LS8 Specifications

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)
operating temperature	41-104° F (5-40 °C)

Weight and Dimensions

weight	1.8 lbs. (1.86 kg)
effective print width	1.00” (25.4 mm)
print length	30.00” (maximum label length)
