USING PAGES
29
The Page Function
The PANTHER™ LS8 provides 9 separate pages for each label. Label items,
including text and tools may be placed on each of the 9 pages. The pages
function is particularly useful for creating non-standard serializations that do
not follow a common increment. The pages function is also useful for creating
text on patch panel labels.
Using the Page Function
The page number icon in the lower right hand corner of the display indicates
the current page. For example, 1:9 indicates that page 1 of 9 is currently
displayed. To change the page, press the PAGE key. Then scroll forward
using the right directional arrow key or backward using the left directional
arrow key. Press ENTER to accept the page change and return to the home
screen.

Panduit PanTher LS8 Specifications

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)
operating temperature	41-104° F (5-40 °C)

Weight and Dimensions

weight	1.8 lbs. (1.86 kg)
effective print width	1.00” (25.4 mm)
print length	30.00” (maximum label length)
