CREATING A DATE OR TIME STAMP
AND CREATING LINES
25
The Date Tool
The Date Tool allows the user to print a date stamp on a label. The date
printed on the label is defined by the internal clock of the PANTHER™ LS8.
Creating a Date Tool
The date tool should be accessed from the home screen. To access the date
tool:
1. Press the INSERT key to enter the tools menu.
2. Press the directional arrows to highlight the date tool.
3. Press the key to select the date tool.
4. On the home screen, the date tool icon will appear at the position of
the cursor.
Editing a Date Tool
To edit a date tool on the home screen, move the cursor directly to the left of
the date tool and then press the INSERT key.
The Time Tool
The Time Tool allows the user to print a time stamp on a label. The time
printed on the label is defined by the internal clock of the PANTHER™ LS8.
Creating a Time Tool
The time tool should be accessed from the home screen. To access the time
tool:
1. Press the INSERT key to enter the tools menu.
2. Press the up directional arrow key to highlight the date tool.
3. Press the key to select the time tool.
4. On the home screen, the time tool icon will appear at the position of
the cursor.
Editing a Time Tool
To edit a time tool on the home screen, move the cursor directly to the left of
the time tool and then press the INSERT key.

Panduit PanTher LS8 Specifications

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)
operating temperature	41-104° F (5-40 °C)

Weight and Dimensions

weight	1.8 lbs. (1.86 kg)
effective print width	1.00” (25.4 mm)
print length	30.00” (maximum label length)
