Panduit PanTher LS8 User Manual

PANTHERLINK
32
Installing PANTHERLINK
Use the PANTHERLINK CD to install PANTHERLINK software onto a personal
computer. The PANTHERLINK CD is available with the purchase of LS8-KIT
or LS8-PCKIT.
Insert the CD into a personal computer. The installation program will begin
automatically. Follow the instructions in the installation wizard in order to
complete the installation process.
PANTHERLINK desktop icon
Using PANTHERLINK
To use PANTHERLINK software with the PANTHER ™ LS8 printer:
1. Connect the USB cable (included with LS8-KIT and LS8-PCKIT) to a
personal computer.
2. Connect the USB cable to the PANTHER™ LS8 at the USB port.
3. Turn ON the PANTHER™ LS8.
4. Press the key to access the setup menu.
5. Use the up or down directional arrow keys to highlight PanTherLink.
6. Press the key. The LS8 is now ready to communicate to a personal
computer.
7. Open PANTHERLINK software on a personal computer.
8. Use PANTHERLINK to transfer label files between the PANTHER™ LS8
and a computer.

Panduit PanTher LS8 Specifications

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)
operating temperature	41-104° F (5-40 °C)

Weight and Dimensions

weight	1.8 lbs. (1.86 kg)
effective print width	1.00” (25.4 mm)
print length	30.00” (maximum label length)
