Panduit TDP43ME User Manual

TDP43ME
TDP43ME: PA26305A01_08 Page 6 of 75 11-2022
Image Handling
Support BMP and PCX. Support ICO, WMF, JPG, EMF file through software. Support
image resize, rotating, mapping and inverse through software.
Resident
Barcodes
Code 39, Code 93, Code 128 (subset A, B, C), UCC/EAN-128 K-Mart, UCC/EAN-128,
UPC A / E (add on 2 & 5), I 2 of 5, I 2 of 5 with Shipping Bearer Bars, EAN 8 / 13 (add on
2 & 5), Codabar, Post NET, EAN 128, DUN 14, MaxiCode, HIBC, Plessey, Random
Weight, Telepen, FIM, China Postal Code, RPS 128, PDF417, Datamatrix code & QR
code
Interfaces
Serial port: RS-232 ( Baud rate : 4800 ~ 115200 , Xon/Xoff , DSR/DTR )
USB port: V2.0
Ethernet TCP/IP Port (wireless – optional)
Control Panel
Two Bi-color LED: Ready, Status
Function Key: FEED
Power Auto Switching 100/240VAC, 50/60 Hz
Environment
Operation: 41°F to 104°F (5°C to 40°C)
Storage: -4°F to 122°F (-20°C to 50°C)
Humidity
Operation: 30-85%, non-condensing. Free air.
Storage: 10-90%, non-condensing. Free air.
Cert. Approval CE, FCC Class A, CCC, CB, cUL, RoHS, WEEE, KC, NOM
Printer Dimension
Length: 11.2” (285 mm)
Height: 6.8” (171 mm)
Width: 8.9” (226 mm)
Weight: 6 lbs. (2.72 Kg)
Specifications are subject to change without notice.

Panduit TDP43ME Specifications

General

Color	Yes
Print technology	-
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Certification	RoHS
Product color	Black, Grey
Cables included	AC, USB

Weight and Dimensions

Width	226 mm
Height	173 mm
Weight	2720 g
