TDP43ME
TDP43ME: PA26305A01_08 Page 9 of 75 11-2022
1-4. Printer Parts
1.
Cover Open Button
2.
Top Cover
3.
Label Roll Core
4.
Ribbon Rewind Wheel
5.
Print Mechanism
6.
Ribbon Rewind Shaft +
Empty Ribbon Roll
7.
Locking Tenon (left/right)
8.
Front Cover Piece
1.
LED Light (Ready)
2.
LED Light (Status)
3.
FEED Key
4.
CF Card Slot Cover
2
1
3
4
5
6
7
8
