Panduit TDP43ME User Manual

TDP43ME
TDP43ME: PA26305A01_08 Page 7 of 75 11-2022
1-3. Communication
Serial Interface
Serial Default
Setting
:
9600 baud rate
､
no parity
､
8 data bits
､
1 stop bit
､
XON/XOFF protocol and
RTS/CTS
。
RS232 HOUSING (9-pin to 9-pin)
DB9 SOCKET
DB9 PLUG
---
1 1
+5V,max 500mA
RXD
2 2
TXD
TXD
3 3
RXD
DTR
4 4
N/C
GND
5 5
GND
DSR
6 6
RTS
RTS
7 7
CTS
CTS
8 8
RTS
RI
9 9
N/C
PC
PRINTER
【 Note 】 The total current output from serial port cannot exceed 500mA.

Panduit TDP43ME Specifications

General

Color	Yes
Print technology	-
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Certification	RoHS
Product color	Black, Grey
Cables included	AC, USB

Weight and Dimensions

Width	226 mm
Height	173 mm
Weight	2720 g
