TDP43ME
TDP43ME: PA26305A01_08 Page 8 of 75 11-2022
USB Interface
Connector Type
:
Type B
PIN NO. 1 2 3 4
FUNCTION VBUS D- D+ GND
Internal Interface
UART1 wafer
Ethernet module
N.C
1 1
N.C
TXD
2 2
RXD
RXD
3 3
TXD
CTS
4 4
RTS
GND
5 5
GND
RTS
6 6
CTS
E_MD
7 7
E_MD
RTS
8 8
CTS
E_RST
9 9
E_RST
+5V
10 10
+5V
GND
11 11
GND
+5V
12 12
+5V
UART2 wafer
Expansion module
+5V
1 1
+5V
CTS
2 2
RTS
TXD
3 3
RXD
RTS
4 4
CTS
RXD
5 5
TXD
GND
6 6
GND
