Digiplex LCD Keypad 17n
6.0 Message Programming
Sections [101] to [148], [200] to [204], and [301] to [396]
Each section contains one message with a maximum of 16
characters. For more details and to record any changes, use the
Digiplex Modules’ Programming Guide.
The DGP-NE96 control panel has up to 8 partitions, 96
zones and up to 999 user codes. The LCD keypad only
allows you to program the messages for up to 4
partitions, 48 zones and 96 user codes. The rest of the
messages can be programmed directly into the DGP-
NE96 control panel. Refer to the DGP-NE96 Reference &
Installation Manual and to the DGP-NE96 Programming
Guide for more details.
After entering the section corresponding to the desired message,
use the Message Programming Keys (refer to Table 6.1 on
page 18) and the Special Function Keys (refer to page 18) to
change the message to suit your installation needs. For example,
section [101] “ZONE 01” can be changed to “FRONT DOOR”.
Section [101] to [148] = “Zone 01” to “Zone 48” respectively
Section [200] = “Paradox Security”
Section [201] to [204] = “First Area”, “Second Area”, “Third
Area”, and “Fourth Area” respectively
Section [301] to [396] = “Code 01” to “Code 96” respectively
