21
NOTE 1: 000 = Occurs in all areas enabled in the system (see section [3031]).
001 = Area 1 003 = Areaarea 3 005 = Area 5 007 = Area 7 255 = Occurs in at least one area enabled in the system.
002 = Area 2 004 = Area 4 006 = Area 6 008 = Area 8
*
: If a Keyswitch Input is used, the input must be defined as “Generates a Utility Key Event on Open” or “Generates a Utility Key Event on Open
and Close”. If a remote control is used, the remote control button must be defined as a Utility Key button.
** This event cannot be used for a module’s PGM programming.
†
: Actions that Activate a Utility Key Event
066 Status 3
000 Intellizone Delay Engaged**
See Note 1
on page 21
001 Fire Delay Engaged
002 Auto Arm
003
Arming with Voice Module (set
until Exit Delay finishes)
004 Tamper
005 Zone Low Battery
006 Fire Loop Trouble
007 Zone Supervision Trouble
Event
Group (G)
Event Group Description Event Number (N) Event Number Description Area Number (A)
