Page 9
Overvi
ew
Module Components -
Bottom View
1)
Power/Input T
erminals: used to connect the PCS300 to an
external power supply such
as the PS817
(optional) and to
connect
up to 2 input
s
2)
Ethernet connector: used
to connect the PCS300 to the
IP
network
3)
R-1/T
-1 and Ring/T
ip T
erminals: used to connect the
PCS300 to the control panel and to the T
elco, respectively
2
1
3
8
10
