Zone Definitions
NOTE: If a device is assigned to a zone which is already programmed, a wireless zone will overwrite a keypad/hardwire zone and a keypad zone will overwrite a
hardwire zone.
To define zones on your SP+ control panel:
1. Press
ENTER, and then enter your installer code (maintenance code may also be used). The ARM and STAY functions will flash.
2. Enter the three-digit zone number you wish to program (e.g., 001 to 032). The
ARM and STAY functions will remain illuminated.
3. Enter a two-digit zone definition, by referring to table 4.
4. Assign a partition, by referring to table 5. By default, all zones are assigned to partition 1.
5. Select or deselect zone options, using buttons 1 to 8 (see tables 6 and 7).
6. Press
ENTER to save and proceed to the next zone.
7. Repeat steps 3 to 6 for all remaining zones.
Table 4: Zone definitions for SP+ Series panels
Input Value Description
Arming Type
Stay Arm Sleep Arm Fully Arm
00 Disabled (default) - - -
01 Entry delay 1 Entry delay 1 Entry delay 1 Entry delay 1
02 Entry delay 2 Entry delay 2 Entry delay 2 Entry delay 2
03 Entry delay 1 (Full Arm) Not armed Not armed Entry delay 1
04 Entry delay 2 (Full Arm) Not armed Not armed Entry delay 2
05 Follow Follow* Follow* Follow
06 Follow (sleep/full arm) Not armed Follow* Follow
07 Follow (full arm) Not armed Not armed Follow
08 Instant Instant* Instant* Instant
09 Instant (sleep/full arm) Not armed Instant* Instant
10 Instant (full arm) Not armed Not armed Instant
11 Instant re† - - -
12 Delayed re† - - -
13 Instant re silent† - - -
14 Delayed re silent† - - -
15 24 hr. buzzer - - -
16 24 hr. burglary - - -
17 24 hr. hold-up - - -
18 24 hr. gas - - -
19 24 hr. heat - - -
20 24 hr. water - - -
21 24 hr. freeze - - -
22 24 hr. panic‡ - - -
23 Follow no pre-alarm - - -
24 Instant no pre-alarm - - -
25 Keyswitch maintain** - - -
26 Keyswitch momentary** - - -
33 Instant no pre-alarm (stay/sleep) Instant Instant Not armed
34 Instant no pre-alarm (sleep) Not armed Instant Not armed
35 Entry delay 1 (stay/full)/instant Entry delay 1 Instant Entry delay 1
36 Entry delay 1 (full arm)/instant Instant Instant Entry delay 1
* Flex-instant: zone will follow the delay at section [720] (default is 15 seconds/0 = instant zone).
** On-board, hardwire, control panel zones only.
† ZX8/ZX82 inputs do not support re zones. For two-wire smoke installations these denitions apply to
zone 1 input only. Section [706], option 3, must be enabled. For four-wire smoke installations, use any panel,
on-board zone input.
‡ This alarm will follow the panic 1 option (section [702], option 1).
Table 5: Partition assignment for SP+ Series panels
Input Value Description
1 Assign to partition 1
2 Assign to partition 2
3 Assign to both partitions
NOTE: When using the K636 keypad, only
partition 1 is available.
Table 6: Zone options for SP+ Series panels
Input
Value
Description
1 Auto zone shutdown
2 Bypassable zone
3RF zone supervision
6 Intellizone
7 Delay alarm transmission
8Force zone
Input Value
Zone Alarm Type
4 5
OFF OFF Audible alarm
OFF ON Pulsed alarm
ON OFF Silent alarm
ON ON Report only
NOTE: For additional zone options, see Zone
Options on page 37.
Table 7: Keyswitch options for SP+ Series panels
Input
Value
Description
1-
2-
3-
4
OFF = Disarm; ON = Disarm only
if Stay/Sleep armed
5Arm only
6Stay arming*
7 Sleep arming*
8-
* Select only one. If all are OFF, keyswitch will
regular arm.

Paradox SP5500+ Specifications

General

StayD Mode	Yes
PGMs	4 programmable outputs
Partitions	2 partitions
Expandable via Bus	Yes
Outputs	4 programmable outputs
Power Supply	1.5A
Battery Backup	7Ah
