SP+ Series Programming Guide
41
Communication Programming
Use the following section to program various communication features on your SP+ Series control panel. Table 33 lists features available for each
SP+ Series control panel.
Prioritization of signals and messages are based on a “first in, first out” scheme. Systems meet EN 50136 ATS2 or ATS3 requirements when configured as depicted.
NOTE: For increased security, it is suggested that redundant communication methods be installed.
Dialer Options
Table 33: Communication features for SP+ Series panels
Communication Feature
Control Panel
SP5500+ SP6000+ SP7000+
GPRS reporting (PCS series)
SMS (PCS series)
IP reporting (IP Module)
E-mail/monitoring (IP Module)
Patented dialer
Table 34: Description of dialer options for landline communication (section [800])
Option Description OFF ON
Option
Description
Section [800]
1 & 2 Telephone line monitoring
See options 1
& 2, on right
See options 1
& 2, on right
3 Switch to pulse on fifth attempt Disabled
Enabled 1 2
4Alternate dial Disabled
Enabled OFF OFF Disabled (default)
5 Force dial (must be enabled to comply with TBR-21)
Disabled Enabled OFF ON Trouble only
6DTMF dialing
Disabled Enabled ON OFF
When disarmed: trouble only; when
armed: audible only
7 Pulse ratio
1:2 1:1.5 ON ON Silent alarms become audible alarm
8Reporting*
Dialer
activated
No dialer
= Default
* This option also applies to landline.
Table 35: Description of general communication dialer options (section [801])
Option Description OFF ON
Section [801]
1 Report system disarming
Always After alarm
2Report zone restore Bell cutoff
Zone closure
3 & 4 Auto-test report transmission
See table 36 on page 41
See table 36 on page 41
5Contact ID override Disabled
CID defaults/slow format
custom
6Future Use - - - -
7Future Use - - - -
8Future Use - - - -
= Default
Table 36: Auto-test report transmission options (section [801])
Option
Description
3 4
1 OFF OFF
Transmit the test report code when the days programmed in section [840] have elapsed, at the time programmed in section
[850] (default).
2OFF ON
When disarmed: transmit test report code when the time programmed in section
[852] has elapsed. When armed: transmit test
report code when the time programmed in section [851] has elapsed.
3ON OFF
The control panel will transmit the test report code every hour, on the minute value programmed in section [850] (the last two
digits); the first two digits of section [850] will be ignored. For example, if 10:25 was programmed into section [850], the test
report code would be transmitted at the 25th minute of every hour, i.e., 11:25, 12:25, etc.
4ON ON
The test report code will be transmitted when the conditions in entries 2 or 3 above (option 3 = OFF and option 4 = ON; option 3
= ON and option 4 = OFF), are met.
