HOW DO I SET THE PROGRAMMABLE OUTPUTS?
Section # Event Group # Sub-Group # Partition #
[120] = PGM1 Start Event ___/___ ___/___ ___/___
[121] = PGM1 Stop Event ___/___ ___/___ ___/___
Can be used as another Start Event if
section [066] is programmed with a
value other than 000.
[122] = PGM2 Start Event ___/___ ___/___ ___/___
[123] = PGM2 Stop Event ___/___ ___/___ ___/___
Can be used as another Start Event if
section [067] is programmed with a
value other than 000.
[124] = Global PGM Start Event___/___ ___/___ ___/___
[125] = Global PGM Stop Event ___/___ ___/___ ___/___
Used to activate PGMs on
expansion modules and LCD keypads
(see page22 and page25)
Example: section [120] = 05 03 02: this means PGM1 will activate whenever partition 2 is Stay Armed.
Event Group # Sub-Group #
00 = Zone OK 01-16 = Zones 1 to 16
99 = Any Zone
01 = Zone Open 01-16 = Zones 1 to 16
99 = Any Zone
02 = Partition Status 00 = System not ready (Partition 1 only)
01 = System ready (Partition 1 only)
02 = Steady Alarm in Partition
03 = Pulsed Alarm in Partition
04 = Pulsed or Steady Alarm in Partition
05 = Alarm in Partition Restored
06 = Bell Squawk Activated (Partition 1 only)
07 = Bell Squawk Deactivated (Partition 1 only)
99 = Any Sub-Group
03 = Global Disarm with User Code 01-48 = User Code Numbers 001 to 048
99 = Any User Code
04 = Special Global Disarm 00 = Disarm with WinLoad Software
01 = Disarm with Keyswitch
99 = Any Sub-Group
05 = Non-Reportable Events 00 = Telephone Line Trouble (Partition 1 only)
01 = [PG] or [FNC1] key was pressed (Partition 1 only)
02 = Instant Arming
03 = Stay Arming
04 = Force Arming
05 = Fast Exit (Force & Regular Only)
06 = PC Fail to Communicate (Partition 1 only)
07 = Midnight (Partition 1 only)
08 = Ground start (Partition 1 only)
99 = Any Sub-Group (Partition 1 only, except 02 to 05)
01 = Partition 1
02 = Partition 2
99 = Any Partition
Sub-Groups proceeded by
(Partition 1 only) cannot be
assigned to activate in partition 2.
