Parker AC30 series Product Manual

5
AC30 series General Purpose I/O Option
Product Specification
Power consumption
(internal)
Sourced from drive’s
internal supplies. Its
purpose is to power the
option module, except
digital outputs.
Maximum consumption
(7004-01-00) = 1W
Power consumption
(external)
Sourced from user supply.
Its purpose is to power
digital outputs.
Maximum consumption
(7004-01-00 only) =
500mA @ 24V

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
