Parker AC30 series Product Manual

1
AC30 series General Purpose I/O Option
AC30 SERIES GENERAL PURPOSE I/O OPTION
Introduction
The General Purpose I/O Option Modules, referred to throughout as
GPIO, is a range of option modules compatible with the AC30 range of
drives. They offer a variety of I/O expansion, according to the full product
code.
Understanding the Product Code
The GPIO product codes are 7004-XX-00 and are available with different
features:
Product Code
Features available
7004-
01
-00
4 x Digital Inputs or Outputs
3 x Analogue Inputs
1 x Motor Thermistor Input
2 x Volt-free Relay Outputs
Real-Time Clock
7004-
02
-00
1 x Motor Thermistor Input
7004-
03
-00
1 x Motor Thermistor Input
Real-Time Clock
7004-XX-
00
Standard optimized minimal conformal coating

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
