Parker AC30 series Product Manual

8
AC30 series General Purpose I/O Option
Programming
Output Ports
The four outputs are included in parameter number 0022.
Parameter
Access
Bit
Value
Description
0022
Write or
Read
00 to
07
x
These bits control digital
outputs on the base I/O.
08
0
DOUT11 = low level output,
or port is configured as
input.
1
DOUT11 = high level output
09
0
DOUT12 = low level output,
or port is configured as
input.
1
DOUT12 = high level output
10
0
DOUT13 = low level output,
or port is configured as
input.
1
DOUT13 = high level output
11
0
DOUT14 = low level output,
or port is configured as
input.
1
DOUT14 = high level output
12 to
13
x
Unused. Value = don’t care
14, 15
x
These control relay outputs
on the GPIO. See page 17.

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
