Parker AC30 series Product Manual

13
AC30 series General Purpose I/O Option
Programming
Parameter
Access
Value
Description
1181
Read only
-100.00% to +100.00%
Value of ANIN11
1182
-100.00% to +100.00%
Value of ANIN12
1183
-100.00% to +100.00%
Value of ANIN13
Specification
Analogue Inputs ANIN11 to ANIN13
Common mode voltage range
±10V X21/01 relative to drive 0V
Input voltage range
-10V to +10V each analogue input
relative to terminal X21/01
Overrange
>2%
Accuracy
Better than ±1%
Absolute maximum input
voltage
-20V to +20V relative to terminal
X21/01
Input impedance
>50kΩ
Resolution
12 bits + sign
Sample rate
1ms
Conformance to standard
EN61131-2:2007

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
