Parker AC30 series Product Manual

10
AC30 series General Purpose I/O Option
Specifications
Digital Inputs DIN11 to DIN14
Feature
Value
Normal operating voltage
0 to 24V relative to terminal
X20/06
Absolute maximum input voltage
-30V to +30V relative to terminal
X20/06
Input threshold
Between 5V and 15V relative to
terminal X20/06
Input hysteresis
None
Input current
8mA to 12mA @ 24V DC
Sample rate
1ms
Isolation
DIN11 to DIN14 are optically
isolated from drive electronics, but
not from other 7004-01-00 Digital
Inputs / Outputs. Isolation is
functional only, intended to
eliminate ground loops. It is not a
safety isolation barrier.
Conformance to standard
EN61131-2:2007
Digital Outputs DOUT11 to DOUT14
Feature
Value
Output high voltage
> X20/05 – 2V
Maximum output current (high
level)
160mA per output
Output leakage current (Low
output level)
<0.1mA
Overload / short circuit
protection
Indefinite. Each output is protected
by a self-resetting fuse.
Update rate
1ms
Isolation
DOUT11 to DOUT14 are optically
isolated from drive electronics, but
not from other 7004-01-00 Digital
Inputs / Outputs. Isolation is
functional only, intended to
eliminate ground loops. It is not a
safety isolation barrier.
Conformance to standard
EN61131-2:2007
State at power-up
Off (low)
