Parker AC30 series Product Manual

2
AC30 series General Purpose I/O Option
Installation
1. Refer to the AC30 product manual Chapter 1: Safety before installing or
removing a GPIO option.
2. Ensure all power is removed from the drive.
3. Remove the GKP by pulling from the top down, and remove.
4. After removing the screw, slide the VCM lower cover down slightly and then
remove.

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
