Parker AC30 Technical Manual

AC30 EtherNet IP Option
Technical Manual
HA501842U001 Issue 2
Copyright 2013 Parker Hannifin Manufacturing Limited
All rights strictly reserved. No part of this document may be stored in a retrieval system, or transmitted in any
form or by any means to persons not employed by a Parker company without written permission from Parker
Hannifin Ltd. Although every effort has been taken to ensure the accuracy of this document it may be
necessary, without notice, to make amendments or correct omissions. Parker cannot accept responsibility for
damage, injury, or expenses resulting therefrom.
Parker Hannifin Manufacturing Limited is referred to throughout this document as Parker.
WARRANTY
The general terms and conditions of sale of goods and/or services of Parker Hannifin Europe Sàrl,
Luxembourg, Switzerland Branch, Etoy, apply to this product unless otherwise agreed. The terms
and conditions are available on our website www.parker.com/termsandconditions/switzerland.

Parker AC30 Specifications

General

Protection Rating	IP20
Series	AC30
Type	Variable Frequency Drive
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Communication Protocols	CANopen
Power Range	0.75 to 250 kW (1 to 350 hp)
Switching Frequency	2kHz to 16kHz
Safety	Safe Torque Off (STO)
Output Current	Model Dependent
Power Rating	0.75 to 250 kW (1 to 350 hp)
Efficiency	>97%
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, overheating
Dimensions	Model Dependent
Weight	Model Dependent
Operating Temperature	-10°C to +40°C
Output Voltage	0 to Input Voltage
