The Keypad
9-32
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
Control Key Definitions
Keys for Programming the Drive
UP
Navigation
- Moves upwards through the list of parameters or menus
Parameter
- Increments the value of the displayed parameter.
Command Acknowledge
- Confirms action when in a command menu.
DOWN
Navigatio
n - Moves downwards through the list of parameters or menus
Parameter
- Decrements the value of the displayed parameter.
ESCAPE
Navigation
- Displays the previous level’s Menu.
Parameter
- Returns to the parameter list.
Trip Message
- Clear the Trip or Error message from the display.
MENU
Navigation
- Displays the next Menu level, or the first parameter of the current
Menu.
Parameter
- Allows a writable parameter to be modified (this is indicated by
→
appearing on the left of the bottom line). Hold to display the PREF.
PROG
PROG
Navigation
- Toggles between current locations within the Operator menu and
any other menu.
LOCAL/
REMOTE
R
L
Control
- Toggles between Remote and Local Mode for both Start/Stop (Seq)
and Speed Control (Ref). When toggling, the display automatically goes to the
relevant SETPOINT screen, and the SETPOINT (LOCAL) screen will have the
and
keys enabled to alter the setpoint.
