Programming D-174
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
TRIPS STATUS
SETUP::TRIPS::TRIPS STATUS
The Drive supports advanced and flexible trip logic to support monitoring of the Drive itself, the motor and the load. This
function block provides a view into the current trip condition(s) and allows some trips to be disabled.
Parameter Descriptions
DISABLED WORD 1
PREF: 97.01
Default: 0300
Range: 0x0000 to 0xFFFF
Use this parameter to disable trips. Not all trips may be disabled, the DISABLED WORD 1 mask is ignored for trips that
cannot be disabled. See below for which trips may be disabled and how this parameter is formed.
DISABLED WORD 2
PREF: 97.02
Default: 0840
Range: 0x0000 to 0xFFFF
Use this parameter to disable trips. Not all trips may be disabled, the DISABLED WORD 2 mask is ignored for trips that
cannot be disabled. See below for which trips may be disabled and how this parameter is formed.
DISABLED WORD 3
PREF: 97.10
Default: 0000
Range: 0x0000 to 0xFFFF
Use this parameter to disable trips. Not all trips may be disabled, the DISABLED WORD 3 mask is ignored for trips that
cannot be disabled. See below for which trips may be disabled and how this parameter is formed.
DISABLED WORD 4
PREF: 97.11
Default: 000
Range: 0x0000 to 0xFFFF
Use this parameter to disable trips. Not all trips may be disabled, the DISABLED WORD 4 mask is ignored for trips that
cannot be disabled. See below for which trips may be disabled and how this parameter is formed.
DISABLED WORD 5
PREF: 97.18
Default: 0000
Range: 0x0000 to 0xFFFF
Use this parameter to disable trips. Not all trips may be disabled, the DISABLED WORD 5 mask is ignored for trips that
cannot be disabled. See below for which trips may be disabled and how this parameter is formed.
DISABLED WORD 6
PREF: 97.19
Default: 0000
Range: 0x0000 to 0xFFFF
Use this parameter to disable trips. Not all trips may be disabled, the DISABLED WORD 6 mask is ignored for trips that
cannot be disabled. See below for which trips may be disabled and how
this parameter is formed.
