E-41 Technical Specifications
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
Analog Inputs/Outputs : 890CD & 890SD
AIN1 - AIN4, AOUT1 - AOUT2
Inputs
Outputs
Range
0-10V, ±10V, 0-20mA or 4-20mA
(range set in software). Absolute
maximum input voltage -15V to +30V
0-10V, ±10V (10mA maximum),
(range set in software)
Impedance
Voltage range = 47kΩ
Current range = 150
Ω
+ series diode
Voltage range = 100Ω
Resolution
12 bit
12 bit
Sample Rate
5ms (one selected input can be 1ms)
5ms
Digital Inputs : 890CD & 890SD
DIN1 - DIN9. Conforming to IEC1131-2.
Nominal Rated Voltage
24V DC
threshold
13V
7V
0V
24V
+30V
-
15V
ON
OFF
Absolute Maximum Input Voltage
-15V to +30V
Input Threshold
9.0V ±2.5V
Input Hysteresis
No
Sample Rate
1ms
Input Current
7.3mA
±
10% @ 24V
