The DAC and ADC values, gains, and offsets are accessed in blocks of eight
parameters each, as shown in the table below. Since each node may
accommodate all 32 analog inputs and outputs, a range of 512 bits is
reserved for each node. The parameter numbers correspond to a range of
33280-33791 for the lowest numbered node, 33792-34303 for the next node,
and so on. The table below shows the parameter mapping for the lowest
number node. For each higher number node, add 512.
DAC Parameter/DAC
number
0 1 … 31
DAC Output Value P33280 P33296 … P33776
Reserved P33281 P33297 … P33777
DAC Gain P33282 P33298 … P33778
DAC Offset P33283 P33299 … P33779
Reserved P33284 P33300 … P33780
Reserved P33285 P33301 … P33781
Reserved P33286 P33302 … P33782
Reserved P33287 P33303 … P33783
ADC Parameter/ADC
number
0 1 … 31
ADC Input Value P33288 P33304 … P33784
Reserved P33289 P33305 … P33785
ADC Gain P33290 P33306 … P33786
ADC Offset P33291 P33307 … P33787
Reserved P33292 P33308 … P33788
Reserved P33293 P33309 … P33789
Reserved P33294 P33310 … P33790
Reserved P33295 P33311 … P33791
These tables appear similar to the other parameter tables for ACR DACs and
ADC’s, but there is no relationship in function. Nor do the other DAC and
ADC commands have any function for ACR9000 extended analog I/O. The
DAC commands assume their use as command outputs for drives, and the
ACR90x0 does not have the type of ADCs that are assumed by other ADC
commands.
140 ACR9000 Series Hardware Installation Guide
