Parker IPA Series User Manual

ELECTRICAL INSTALLATION
48 IPA Hardware Installation Guide
Brake Relay Connector (on Output Power
Connector)
Brake Relay Operation
Brake Relay Operation
Drive Condition
Relay State
Enabled
Closed (conducting)
Faulted
Open
No AC power on L1 and L2* or
drive not enabled
Open
* Mains Control power on C1 and C2 does not affect the relay. With
mains power applied to C1 and C2, the relay remains open if AC power
is not applied to the L1 and L2 terminals.
Brake Relay Specifications
Warning: Do not exceed the ratings of the brake relay. If required, control
a suitable external relay with this relay to meet your power
requirements.
Description
Connections
Models
IPA04, IPA15
Connector Type
Removable screw terminal
Terminals
6
Pitch
0.200 in (5.08 mm)
Wire range
12-26 AWG
14-27 SWG
(0.12-3.30 mm2)
Wire strip length
0.310 in (8 mm)
Torque
7.0 in–lbs nom. (0.79 N-m)
Description
Specification
Relay Type
Solid State Relay
Normally open
Relay Maximum Rating
1 Amp at 24 VDC
