Parker P1/PD Series User Manual

Parker Hannin Corporation
Hydraulic Pump and Power Systems Division
Marysville, Ohio USA
Bulletin HY28-2708-02/SVC/EN | July 2019
Medium Pressure Axial Piston Pumps
P1/PD B-mod Service Information
11
Item
No
Qty 060 Part No 075 Part No 085 Part No 100 Part No 140 Part No Description
1
4
(2: 075/085)
361-13250-0 361-13270-0 361-13270-0 361-14290-0 361-15270-0
Socket head cap screws (non-thru drive version)
0
(2: 075/085)
361-13250-0 361-13250-0 361-13250-0 361-14290-0 361-15270-0
4 361-13250-0 361-13250-0 361-13250-0 361-14290-0 361-15267-0 Socket head cap screws (thru drive version only)
2* 2 108X8V 108X8V 108X8V 108X8V 108X8V Volume stop boss plug & O-ring
3 1 Contact factory for port block ordering information. Port block
4* 1 675-00164-0 675-00165-0 675-00165-0 675-00169-0 675-00173-0 Port block O-ring
5* 2 108X2V 108X2V 108X2V 108X2V 108X2V Boss plug & O-ring
6 1 226X42 226X42 226X42 226X42 226X42 M5X6 control ow set screw
7 1 324-30014-0 324-30014-0 324-30014-0 324-30014-0 324-30014-0 Port plate pin
8* 3 605-10070-0 605-10070-0 605-10070-0 605-10070-0 605-10070-0 Control pressure O-rings
9*** 1
03E-94038-0 03E-93169-0 03E-93169-0 03E-95605-0 03E-93252-0 Port plate, CW, industrial (PD)
03E-94039-0 03E-93170-0 03E-93170-0 03E-95606-0 03E-93253-0 Port plate, CCW, industrial (PD)
03E-94040-0 03E-93171-0 03E-93171-0 03E-95607-0 03E-93254-0 Port plate, CW, mobile (P1)
03E-94041-0 03E-93172-0 03E-93172-0 03E-95608-0 03E-93255-0 Port plate, CCW, mobile (P1)
10* 2 695-00912-0 695-00912-0 695-00912-0 695-00914-0 695-00916-0 Bias and control rod O-ring
11 1
03E-94054-0 03E-93150-0 03E-93150-0 03E-93800-0 03E-93248-0 Bias guide
03E-94832-0 03E-94498-0 ** 03E-94827-0 03E-94743-0 Bias guide (overcenter option “X”)
12
1 03E-94053-0 03E-93149-0 03E-93149-0 03E-93799-0 03E-94658-0 Bias piston
1 03E-94835-0 03E-93149-0 ** 03E-93799-0 03E-94658-0 Bias piston (overcenter option "X")
13 1
03E-94055-0 03E-93151-0 03E-93151-0 03E-93801-0 03E-93963-0 Bias spring
03E-94834-0 03E-94499-0 ** 03E-94829-0 03E-94752-0 Bias spring (overcenter option “X”)
14 1
03E-94052-0 03E-93148-0 03E-95471-0 03E-93798-0 03E-97335-0 Control guide
03E-94833-0 03E-94608-0 ** 03E-94828-0 03E-93246-0 Control guide (overcenter option “X”)
15 1 03E-94051-0 03E-93147-0 03E-93147-0 03E-93797-0 03E-94751-0 Control piston
16* 2 108X4V 108X4V 108X4V 108X4V 108X4V Boss plug & O-ring
17 1 S2E-18591-0K S2E-18591-0K S2E-18591-0K S2E-18640-0K S2E-18527-0K
Bearing shim kit (includes all standard shim
sizes)
18 1 230-82237-0 230-82237-0 230-82237-0 230-82244-0 230-82239-0 Tapered roller bearing cup
19 1 INCLUDED IN ITEM 18 230-82518-0
INCLUDED IN ITEM 18 Tapered roller bearing cone
20 1 356-65152-0 356-65144-0 356-65144-0 356-65146-0 356-65147-0 Retaining ring, internal
21 1 03E-94049-0 03E-93145-0 03E-93145-0 03E-93795-0 03E-93959-0 Barrel hold down spring
22 1 03E-94050-0 03E-93146-0 03E-93146-0 03E-93796-0 03E-93244-0 Barrel hold down washer
23 1 03E-94036-0 03E-93129-0 03E-95465-0 03E-95603-0 03E-93242-0 Barrel
24 3 03E-95904-0 03E-95905-0 03E-95905-0 03E-95906-0 03E-95907-0 Barrel hold down pin
25 1 03E-94047-0 03E-93142-0 03E-93142-0 03E-93794-0 03E-93241-0 Spherical washer
26 1 03E-97012-0 03E-93139-0 03E-95501-0 03E-93793-0 03E-93240-0 Retainer plate
27 9 S2E-18296-0 S2E-17003-0 S2E-19330-0 S2E-17912-0 S2E-17323-0 Piston and shoe assembly
28 1
03E-94032-0 03E-97070-0 03E-97070-0 03E-93779-0 03E-93227-0 01 shaft, no thru drive
03E-94033-0 03E-94000-0 03E-94000-0 03E-93780-0 03E-93228-0 01 shaft with thru drive
S2E-19669-0 S2E-19673-0 S2E-19673-0 S2E-19677-0 S2E-19681-0 02 shaft assembly with key (no thru drive)
S2E-19670-0 S2E-19674-0 S2E-19674-0 S2E-19678-0 S2E-19682-0 02 shaft assembly (thru drive)
S2E-19671-0 S2E-19675-0 S2E-19675-0 S2E-19679-0 S2E-19683-0 04 shaft assembly with key (no thru drive)
S2E-19672-0 S2E-19676-0 S2E-19676-0 S2E-19680-0 S2E-19684-0 04 shaft assembly (thru drive)
03E-95611-0 ** ** 03E94500-0 ** 06 (100cc) & 09 (60cc) shaft, no thru drive
03E-96177-0 ** ** 03E-94462-0 ** 06 (100cc) & 09 (60cc) shaft, thru drive
03E-96216-0 ** ** ** ** 10 shaft, no thru drive
29 1 S2E-18411-0 S2E-17443-0 S2E-17443-0 S2E-17961-0 S2E-17957-0 Cam
30 2 03E-93763-0 03E-93763-0 03E-93763-0 03E-93763-0 03E-93763-0 Bearing retainer screws
31 2 03E-94057-0 03E-93950-0 03E-93950-0 03E-93952-0 03E-93953-0 Cam bearing
32 1 230-82236-0 230-82236-0 230-82236-0 230-82519-0 230-82241-0 Tapered roller bearing cone (and cup 140)
33 1 230-82235-0 230-82235-0 230-82235-0 230-82245-0 ** Tapered roller bearing cup
34 1 226X56 226X56 226X56 226X56 226X56 M6X6 bias ow set screw
35 1 ** ** ** ** ** Housing (not sold separately)
36* 2
108X10V 108X12V 108X12V
108X12V 108X16V Case drain plug & O-ring - SAE ORB
788175V 788175V 788175V 788175V 447-00038-5 Case drain plug & O-ring - BSPP
788516-10V 788516-12V 788516-12V 788516-12V 788516-16V Case drain plug & O-ring - ISO
37* 1
108X4V 108X4V 108X4V 108X4V 108X4V BG port plug & O-ring - SAE ORB
789189V 789189V 789189V 789189V 789189V BG port plug & O-ring - BSPP
788516-04V 788516-04V 788516-04V 788516-04V 788516-04V BG port plug & O-ring - ISO
39* 1 620-82118-5 620-82118-5 620-82118-5 620-82121-5 620-82120-5 Shaft seal
40 1 356-65146-0 356-65146-0 356-65146-0 356-65147-0 356-65148-0 Seal retainer
41 1 See separate compensator ordering information. Compensator
* Denotes seal or O-ring is included in the seal kit | *** Contact factory for overcenter "X" port plate part number information
060, 075, 085, 100, 140 Pump Parts
