Parker P1/PD Series User Manual

Parker Hannin Corporation
Hydraulic Pump and Power Systems Division
Marysville, Ohio USA
Bulletin HY28-2708-02/SVC/EN | July 2019
Medium Pressure Axial Piston Pumps
P1/PD B-mod Service Information
6
Typical Characteristics
Typical Adjustment Ranges and Initial Settings for B-Mod Controls (Unless Customer Specified at Time of Order)
Function Adjustment Range Adjustment Value Recommended or Initial Setting
Pressure compensator settings
C, L, AM Controls 26-280 bar (380-4060 PSI) 55 bar/turn (800 PSI/turn) Default factory setting = 1000 PSI
Load sense differential settings
"L0" and “L2” 10-40 bar (150-580 PSI) 16 bar/turn (230 PSI/turn) 20 bar (290 PSI)
Maximum volume stop
018 100-40% 9% per turn (1.6 cc/turn) 100%
028 100-40% 8.2% per turn (2.3 cc/turn) 100%
045 100-20% 7.5% per turn (3.4 cc/turn) 100%
060 100-30% 6.8% per turn (4.1 cc/turn) 100%
075/085 100-35% 6.2% per turn (4.65 cc/turn) 100%
100 100-50% 5.5% per turn (5.5 cc/turn) 100%
140 100-50% 4.8% per turn (6.72 cc/turn) 100%
Minimum volume stop
018 0-68% 10% per turn (1.8 cc/turn) 0%
028 0-40% 9% per turn (2.6 cc/turn) 0%
045 0-40% 8.2% per turn (3.7 cc/turn) 0%
060 0-50% 4.6% per turn (2.76 cc/turn) 0%
075/085 0-45% 4.3% per turn (3.23 cc/turn) 0%
100 0-45% 3.9% per turn (3.9 cc/turn) 0%
140 0-25% 3.3% per turn (4.62 cc/turn) 0%
Model
P1/PD
018
P1/PD
028
P1/PD
045
P1/PD
060
P1/PD
075
P1/PD
085
P1/PD
100
P1/PD
140
Maximum Displacement, cm
3
/rev
cu.in./rev
18
1.10
28
1.71
45
2.75
60
3.66
75
4.58
85
5.19
100
6.01
140
8.54
Outlet Pressure – Continuous
280 bar
(4060 psi)
250 bar
(3600 psi)
280 bar
(4060 psi)
Intermittent*
320 bar
(4640 psi)
300 bar
(4350 psi)
320 bar
(4640 psi)
Peak
350 bar
(5075 psi)
320 bar
(4600 psi)
350 bar
(5075 psi)
P1 Maximum Speed (1.3 bar abs inlet), rpm 3500 3400 3100 2800 2700 2700 2500 2400
P1 (1.0 bar abs inlet), rpm 3300 3200 2800 2500 2400 2400 2250 2100
P1 (0.8 bar abs inlet), rpm 2900 2900 2400 2200 2100 2100 1900 1800
PD Maximum Speed (1.0 bar abs inlet), rpm 1800
PD (0.8 bar abs inlet), rpm 1800
Minimum Speed, rpm 600
Inlet Pressure – Maximum 11 bar absolute (160 psi)
Rated 1.0 bar absolute (14.5 psi)
Minimum 0.8 bar absolute (11.6 psi)
Case Pressure – Peak, bar 4.0 bar absolute (58 psi) and less than 0.5 bar (7.3 psi) above inlet pressure
Rated, bar 2.0 bar absolute (29 psi) and less than 0.5 bar (7.3 psi) above inlet pressure
Fluid Temperature Range, °C
°F
-40 to +95
-40 to +203
Fluid Viscosity – Rated, cSt 7 to 160
Optimum Range, cSt 14-50 cSt.
Max. Intermittent, cSt 5000 (for cold starting)
Min. Intermittent, cSt 5
Fluid Contamination – Rated, ISO 20/18/14
Weight – End Port, kg (lb) 13.4 (29.5) 17.7 (39.0) 23 (50) 29 (64) 30 (66) 30 (66) 51 (112) 66 (145)
Side Port, kg (lb) 14.2 (31.3) 18.1 (40.0) 24 (52) 30 (67) 31 (68) 31 (68) 53 (117) 67 (147)
Thru-Drive, kg (lb) 15 (34) 22 (48) 27 (59) 34 (75) 35 (77) 35 (77) 55 (121) 82 (180)
Moment of Inertia kg·mm
2
760 1555 3208 4548 5041 5041 12027 21400
Moment of Inertia Thru-Drive kg·mm
2
793 1618 3268 4687 5207 5207 12402 22343
*Intermittent pressure is dened as less than 10% of operation time, not exceeding 6 successive seconds.
