Parker P1/PD Series User Manual

Parker Hannin Corporation
Hydraulic Pump and Power Systems Division
Marysville, Ohio USA
Bulletin HY28-2708-02/SVC/EN | July 2019
Medium Pressure Axial Piston Pumps
P1/PD B-mod Service Information
9
Item No Qty 018 Part No 028 Part No 045 Part No Description
1
4 210x209 210x211 361-12229-0 Socket head cap screws
4 ** 210x209 ** Socket head cap screws (28cc thru drive version only)
2* 2 108X8V 108X8V 108X8V Volume stop boss plug & O-ring
3 1 Contact factory for port block ordering information. Port block
4* 1 2050V-7 2160V-7 675-00162-0 Port block O-ring
5* 4 108X2V 108X2V 108X2V Boss plug & O-ring
6 1 226X42 226X42 226X42 M5X6 Control Flow Set Screw
7 1 299X67 324-30014-0 324-30014-0 Port plate pin
8* 3 605-10077-0 605-10077-0 605-10077-0 Control pressure passage o-rings
9*** 1
03E-94415-0 03E-94969-0 03E-94339-0 Port plate, CW, industrial (PD)
03E-94414-0 03E-94970-0 03E-94340-0 Port plate, CCW, industrial (PD)
03E-94413-0 03E-94969-0 03E-94341-0 Port plate, CW, mobile (P1)
03E-94416-0 03E-94970-0 03E-94342-0 Port plate, CCW, mobile (P1)
03E-94963-0 03E-94376-0 03E-95374-0 Port plate, CW, industrial (PD), ripple chamber
03E-94964-0 03E-94377-0 03E-95080-0 Port plate, CCW, industrial (PD), ripple chamber
03E-94965-0 03E-94378-0 03E-95374-0 Port plate, CW, mobile (P1), ripple chamber
03E-94966-0 03E-94379-0 03E-95375-0 Port plate, CCW, mobile (P1), ripple chamber
10* 2 ** ** 695-00912-0 Bias and control rod O-ring
11
1 03E-94427-0 03E-94390-0 03E-94355-0 Bias guide
1 ** ** 03E-95658-0 Bias guide (overcenter option)
12 1 03E-94428-0 03E-94391-0 03E-94354-0 Bias piston
13
1 03E-94430-0 03E-94393-0 03E-94356-0 Bias spring
1 ** ** 03E-95656-0 Bias spring (overcenter option)
14
1 03E-94427-0 03E-94390-0 03E-94353-0 Control guide
1 ** ** 03E-95657-0 Control guide (overcenter option)
15 1 03E-94426-0 03E-94389-0 03E-94352-0 Control piston
16 1 226X14 226X56 102x1 Ripple chamber plug (side ported version only)
17 2 299X123 299X123 299X123 Cover dowel pin
18 1 216-10013-0 789814 230-82227-0 Port block bushing
19 1 102X8V 102X8V 108X10V Ripple chamber plug
20 1 256X521 256X525 356-65144-0 Retaining ring, internal
21 1 787635 03E-94387-0 03E-94350-0 Barrel hold down spring
22 2 (1:045) 786996 03E-94388-0 03E-94351-0 Barrel hold down washer
23 1 03E-94717-0 03E-94375-0 03E-94338-0 Barrel
24 3 787000 03E-94386-0 03E-95903-0 Barrel hold down pin
25 1 787002 03E-94385-0 03E-96852-0 Spherical washer
26 1 786994 03E-97011-0 03E-96988-0 Retainer plate
27 9 789641 S2E-18415-0 S2E-18413-0 Piston and shoe assembly
28 1
03E-94409-0 03E-97070-0 03E-97070-0 01 shaft option, no thru drive
03E-94411-0 03E-94374-0 03E-94337-0 01 shaft option with thru drive
S2E-19657-0 S2E-19661-0 S2E-19665-0 02 shaft option assembly with key (no thru drive)
S2E-19658-0 S2E-19662-0 S2E-19666-0 02 shaft option assembly (thru drive)
S2E-19659-0 S2E-19663-0 S2E-19667-0 04 shaft option assembly with key (no thru drive)
S2E-19660-0 S2E-19664-0 S2E-19668-0 04 shaft option assembly (thru drive)
03E-94718-0 ** ** 06 shaft option assembly (no thru drive)
03E-96233-0 ** ** 06 shaft option assembly (thru drive)
03E-94804-0 03E-95166-0 03E-94990-0 08 shaft option, (no thru drive)
03E-94762-0 03E-95492-0 03E-95197-0 08 shaft option (thru drive)
29 1 S2E-19079-0 S2E-18414-0 S2E-18412-0 Cam
30 2 03E-94359-0 03E-94359-0 03E-94359-0 Bearing retainer screws
31 2 03E-94432-0 03E-94395-0 03E-94358-0 Cam bearing
32 1 230-82515-0 789815 230-82516-0 Cylindrical roller bearing
34 1 226X56 226X56 226X56 M6X6 bias ow set screw
35 1 ** ** ** Housing (not sold separately)
36* 2
108X6V 108X8V 108X10V Case drain plug & O-ring - SAE ORB
788153V 788161V 788161V Case drain plug & O-ring - BSPP
788516-06V 788516-10V 788516-10V Case drain plug & O-ring - ISO
37* 1
108X4V 108X4V 108X4V BG port plug & O-ring - SAE ORB
789189V 789189V 789189V BG port plug & O-ring - BSPP
788516-04V 788516-04V 788516-04V BG port plug & O-ring - ISO
38* 1 P2-000-3506-08 P2-000-3506-08 ** M6X6 set screw with 0.8mm orice
39* 1 787140 P2-060-3304 620-82125-5 Shaft seal
40 1 256X535 256X544 356-65158-0 Seal retainer
41 1 See separate compensator ordering information Compensator
42 1 256X222 256X222 356-65159-0 External retaining ring (shaft)
43 1 256X544 256X544 ** Internal retaining ring (housing)
* Denotes seal or O-ring is included in the seal kit
| *** Contact factory for 045 overcenter "X" port plate part number information
018, 028, 045 Pump Parts
