Parker P1/PD Series User Manual

Parker Hannin Corporation
Hydraulic Pump and Power Systems Division
Marysville, Ohio USA
Bulletin HY28-2708-02/SVC/EN | July 2019
Medium Pressure Axial Piston Pumps
P1/PD B-mod Service Information
32
B-mod Seal Kits
018 028 045 060 075/085 100 140
S2E-20278-5K S2E-20279-5K S2E-20280-5K S2E-20281-5K S2E-20282-5K S2E-20283-5K S2E-20284-5K
Note: Seal kits contain all the seals required for any pump conguration including controls.
Rotating Group
Kits
018 028 045 060 075/085 100 140
CW Mobile P1 S2E-18710-0K S2E-19119-0K S2E-19067-0K S2E-18698-0K S2E-18032-0K S2E-18485-0K S2E-18489-0K
CW Mobile P1
w/ Ripple Chamber
S2E-19205-0K S2E-19209-0K S2E-19235-0K ** ** ** **
CCW Mobile P1 S2E-18711-0K S2E-19120-0K S2E-19068-0K S2E-18699-0K S2E-18033-0K S2E-18486-0K S2E-18490-0K
CCW Mobile P1
w/ Ripple Chamber
S2E-19206-0K S2E-19210-0K S2E-19236-0K ** ** ** **
CW Industrial PD S2E-18712-0K S2E-19121-0K S2E-19069-0K S2E-18700-0K S2E-18483-0K S2E-18487-0K S2E-18491-0K
CW Industrial PD
w/ Ripple Chamber
S2E-19207-0K S2E-19211-0K S2E-19126-0K ** ** ** **
CCW Industrial PD S2E-18713-0K S2E-19122-0K S2E-19070-0K S2E-18701-0K S2E-18484-0K S2E-18488-0k S2E-18492-0K
CCW Industrial PD
w/ Ripple Chamber
S2E-19208-0K S2E-19212-0K S2E-19127-0K ** ** ** **
Rotating Group Kit includes barrel s/a, pistons, retainer, washer, pins and port plate.
Kit #1
S2E-20463-5K
Item Description
21 Differential inner spring guide
22 Differential inner spring
23 Differential outer spring
24 Differential outer spring guide
25 Differential inner spring guide O-ring
26 Differential inner spring guide O-ring
27 Differential main O-ring
28 Differential outer plug
29 Differential adjustment lock nut
30 Differential adjustment screw
Control Adapter Block Assemblies
B-mod control on A-mod CW Pump S2E-20301-5
B-mod control on A-mod CCW Pump S2E-20302-5
A-mod control on B-mod Pump (CW or CCW) S2E-20325-5
Kit #3
S2E-20465-5K
Item Description
2 M5 x 6 set screw
16 M5 x 6 set screw
17 M4 x 5 set screw
18 Boss plug & O-ring - SAE
18 Boss plug & O-ring - Metric
18 Boss plug & O-ring - BSPP
19 Boss plug & O-ring
Kit #2
S2E-20464-0K
Item Description
2 M5 x 6 set screw with 0.8mm orice
16 M6 x 6 set screw
20 AM remote differential spool
Kit #4
S2E-20466-5K
Item Description
2 M5 x 6 set screw
16 M6 x 6 set screw with 0.4mm orice
20 L0 & L2 load sense differential spool
B-mod Control Conversion Kits and Contents
Parts Kits
