Parker P1D Series User Manual

13
P1D Cylinder
05.03
www.parker.com/euro_pneumatic
Main data: P1D
Cylinder Cylinder Piston rod Cushioning Air con- Connection Flexible Porting
designation bore area dia. area thread length sump- thread tubing dimension
tion
2)
Push-in
mm cm
2
mm cm
2
mm litre mm
P1D-•032••-XXXX
1)
32 8,0 12 1,1 M10x1,25 17 0,105 G1/8 4 or 6
P1D-•040••-XXXX
1)
40 12,6 16 2,0 M12x1,25 19 0,162 G1/4 4 or 6
P1D-•050••-XXXX
1)
50 19,6 20 3,1 M16x1,5 20 0,253 G1/4 8 or 10
P1D-•063••-XXXX
1)
63 31,2 20 3,1 M16x1,5 23 0,414 G3/8 8 or 10
P1D-•080••-XXXX
1)
80 50,3 25 4,9 M20x1,5 23 0,669 G3/8 -
P1D-•100••-XXXX
1)
100 78,5 25 4,9 M20x1,5 27 1,043 G1/2 -
P1D-•125••-XXXX
1)
125 122,7 32 8,0 M27x2 30 1,662 G1/2
Total mass including moving parts
Cylinder Total mass (kg) Supplement mass (kg) Total mass (kg)
designation at 0 mm stroke for rod locking Supplement per 10 mm stroke
Standard Tie-Rod Clean/Flex All variants Standard Tie-Rod Clean/Flex
P1D-•032••-X 0,55 0,54 0,60 0,31 0,023 0,022 0,047
P1D-•040••-X 0,80 0,79 0,88 0,44 0,033 0,030 0,063
P1D-•050••-X 1,20 1,20 1,32 0,61 0,048 0,048 0,094
P1D-•063••-X 1,73 1,73 1,86 1,25 0,051 0,051 0,101
P1D-•080••-X 2,45 2,47 2,63 2,45 0,075 0,079 0,142
P1D-•100••-X 4,00 4,00 4,22 3,72 0,084 0,084 0,168
P1D-•125••-X 6,87 6,73 7,01 6,07 0,138 0,129 0,248
Mass moving parts only (for cushioning calculation)
Cylinder Mass moving parts(kg)
designation at 0 mm stroke Supplement per 10 mm stroke
All variants All variants
P1D-•032••-X 0,13 0,009
P1D-•040••-X 0,24 0,016
P1D-•050••-X 0,42 0,025
P1D-•063••-X 0,50 0,025
P1D-•080••-X 0,90 0,039
P1D-•100••-X 1,10 0,039
P1D-•125••-X 2,34 0,063
1) Stroke
2) Free air consumption per 10 mm stroke for a double stroke at 6 bar
Cyl. bore/ Stroke Pistonarea Max theoretical force in N (bar)
pist. rod mm cm
2
1,0 2,0 3,0 4,0 5,0 6,0 7,0 8,0 9,0 10,0
32/12 + 8,0 80 161 241 322 402 483 563 643 724 804
- 6,9 69 138 207 276 346 415 484 553 622 691
40/16 + 12,6 126 251 377 503 628 754 880 1005 1131 1257
- 10,6 106 212 318 424 530 636 742 848 954 1060
50/20 + 19,6 196 393 589 785 982 1178 1374 1571 1767 1963
- 16,5 165 330 495 660 825 990 1155 1319 1484 1649
63/20 + 31,2 312 623 935 1247 1559 1870 2182 2494 2806 3117
- 28,0 280 561 841 1121 1402 1682 1962 2242 2523 2803
80/25 + 50,3 503 1005 1508 2011 2513 3016 3519 4021 4524 5027
- 45,4 454 907 1361 1814 2268 2721 3175 3629 4082 4536
100/25 + 78,5 785 1571 2356 3142 3927 4712 5498 6283 7069 7854
- 73,6 736 1473 2209 2945 3682 4418 5154 5890 6627 7363
125/32 + 122,7 1227 2454 3682 4909 6136 7363 8590 9817 11045 12272
- 114,7 1147 2294 3440 4587 5734 6881 8027 9174 10321 11468
Note!
Select a theoretical force 50-100%
larger than the force required
+ = Outward stroke
- = Return stroke
Cylinder forces, double acting variants
