6
P1D Cylinder
05.03
www.parker.com/euro_pneumatic
P1D Clean
P1D Clean is a new version in our ISO cylinder system,
completely designed for the foodstuffs industry. Many
years’ experience of the stringent requirements for
hygiene, choice of material and corrosion resistance, from
a wide spectrum of foodstuffs applications have guided
the development of this cylinder version. Great emphasis
has been put on the external design of the cylinder, choice
of materials and corrosion protection.
Main dimensions according to international standards
All the main dimensions of the P1D Clean comply with ISO
6431, ISO 15552, VDMA 24562 and AFNOR standards.
The exception is the somewhat larger footprint of the end
covers and envelope of the body extrusion, due to the so-
called positive geometry (hygienic, convex, easy-to-clean
geometry) of the cushioning adjustment screw and the
components in the integrated sensor system.
Common, high technology design platform
The P1D Clean has the same technical platform as the
P1D Standard. The best materials, including the
polyurethane (PUR) seals, manufacturing methods and
the careful attention to detail design give the P1D Clean
smooth, quiet operation and long service life.
Convex shape for optimum hygiene
P1D Clean has a convex body extrusion, which makes the
cylinders easy to keep clean. Irrespective of installation
position, fluids run off the body extrusion surfaces.
