5
P1D Cylinder
05.03
www.parker.com/euro_pneumatic
Complete accessory programme
P1D offers a complete ISO, VDMA and AFNOR
compatible accessory programme, with a wide range of
piston rod and cylinder mountings for both pivoted and
fixed operation. Several of these types of mountings are
available in stainless steel. The new ”drop-in” sensors are
available with both reed and electronic operation, with a
wide choice of connector types and cable lengths.
New, mechanically protected sensor technology
The body extrusion has recessed sensor grooves on three
sides of the cylinder. The new sensors are of the ”drop-in”
type, and are quickly and easily installed in the T-groove
from the side. Both the cable and the sensor are protected
in the groove. Choose a sensor with 3 or 10 m cable,
8 mm connector or the new M12 connector.
Optimised cushioning
Thanks to the plastic inserts in the end covers, each
cylinder bore has been given individual flow geometry.
This provides optimised cushioning, which is quicker and
easier to set and adjust.
Smooth, quiet operation and long service life
All seals and end-of-stroke washers are made from
polyurethane (PUR), the bearings and piston are made
from proven engineering plastics with excellent bearing
properties and all cylinders are greased at the factory with
a transparent, foodstuffs-approved grease. Altogether this
gives the P1D very long service life and smooth, quiet
operation.
