P1D Cylinder
05.03
www.parker.com/euro_pneumatic
Straight or elbow push-in fittings for Ø32-63 mm
For cylinder bore Ø32-63 mm, one connection is located
on the body extrusion. The connector from the Moduflex
valve range is used for this connection. A matching
Prestolok 2 (plastic) fitting is used for the connection at the
end cover. Choose between straight or elbow fittings. The
other end has a plug installed in the unused cylinder port.
Threaded connections for Ø80-125 mm
Cylinder bore Ø80-125 mm have two threaded
connections located in either end cover. The other end
has plugs in the cylinder ports. These plugs can be
moved to the other end to suit the application.
Mechanically protected ”drop-in” sensors
The body extrusion, which is common to all P1D Clean
and P1D Flexible Porting cylinders, has recessed sensor
grooves in the side opening. The geometry has at the
same time been designed for ”normal” mechanical sensor
installation (similar to P1D Standard) and for the built-in
sensor system (P1D Clean). Use standard sensors in the
usual way.
Combine with P1D Clean
For compact applications with stringent hygiene
requirements, P1D Clean can be combined with Flexible
Porting. This cylinder version complies with many different
requirements and offers new opportunities for creating
effective application solutions.
