Parker Hannifin
P series User Guide 20
1.4 Illustrations in this Installation Guide
Typically, the illustrations in this guide show the P series PD-04xx, PD-10xx and the
PD-35xx. These three models represent other models with similar features.
PD-04xx represents models PD-01xx and PD02xx. Model PD-10xx represents the PD-08
and Model PD-35xx represents the PD-20.
If there is a need to illustrate differences between drives, relevant drawings are shown for
each drive.
1.3 Assumptions of Technical Experience
The PD Drive is designed for industrial applications. To effectively install and troubleshoot
the PD Drive, you must have a fundamental understanding of the following:
• Motion control applications
• Electromechanical actuators
• Electrical concepts such as voltage, current, switches, etc.
• Serial Communication (RS-422) depending on which communications protocol you are
using.
For solutions to your questions about implementing the PD Drive, first refer to this manual.
If you cannot find the answer in this documentation, contact your distributor for assistance.
If you need to talk to our in-house Application Engineers, please contact us at the
telephone numbers listed on page 2.
