Parker PD-10 Series User Manual

Parker Hannifin
P series User Guide 74
8960
0x2300
Jog Operation
Speed
0x2300
INT
500
-6000
6000
rpm
RW
8961
0x2301
Speed Command
Acceleration Time
0x2301
UINT
200
0
10000
ms
RW
8962
0x2302
Speed Command
Deceleration Time
0x2302
UINT
200
0
10000
ms
RW
8963
0x2303
Speed Command S-
curve Time
0x2303
UINT
0
0
1000
ms
RW
8964
0x2304
Program Jog
Operation Speed 1
0x2304
INT
0
-6000
6000
rpm
RW
8965
0x2305
Program Jog
Operation Speed 2
0x2305
INT
500
-6000
6000
rpm
RW
8966
0x2306
Program Jog
Operation Speed 3
0x2306
INT
0
-6000
6000
rpm
RW
8967
0x2307
Program Jog
Operation Speed 4
0x2307
INT
-500
-6000
6000
rpm
RW
8968
0x2308
Program Jog
Operation Time 1
0x2308
UINT
500
0
10000
ms
RW
8969
0x2309
Program Jog
Operation Time 2
0x2309
UINT
5000
0
10000
ms
RW
8970
0x230A
Program Jog
Operation Time 3
0x230A
UINT
500
0
10000
ms
RW
8971
0x230B
Program Jog
Operation Time 4
0x230B
UINT
5000
0
10000
ms
RW
8972
0x230C
Index Pulse Search
Speed
0x230C
INT
20
-1000
1000
rpm
RW
8973
0x230D
Speed Limit
Function Select
0x230D
UINT
0
0
3
-
RW
8974
0x230E
Speed Limit Value at
Torque Control
Mode
0x230E
UINT
1000
0
6000
rpm
RW
8975
0x230F
Over Speed
Detection Level
0x230F
UINT
6000
0
10000
rpm
RW
8976
0x2310
Excessive Speed
Error Detection Level
0x2310
UINT
5000
0
10000
rpm
RW
8977
0x2311
Servo-Lock Function
Select
0x2311
UINT
0
0
1
-
RW
Table 37. Speed Operation Parameters
4.3.5 Miscellaneous Parameters
communication
address
parameter name
parameter
No.
Variable
Format
Default
Value
Min
Max
Unit
Accessibil
ity
decim
al
hexade
cimal
9216
0x2400
Software Position
Limit Function Select
0x2400
UINT
0
0
3
-
RW
9217
0x2401
INPOS1 Output
Range
0x2401
UINT
100
0
60000
UU
RW
9218
0x2402
INPOS1 Output Time
0x2402
UINT
0
0
1000
ms
RW
9219
0x2403
INPOS2 Output
Range
0x2403
UINT
100
0
60000
UU
RW
9220
0x2404
ZSPD Output Range
0x2404
UINT
10
0
6000
rpm
RW
9221
0x2405
TGON Output Range
0x2405
UINT
100
0
6000
rpm
RW
9222
0x2406
INSPD Output Range
0x2406
UINT
100
0
6000
rpm
RW
9223
0x2407
BRAKE Output Speed
0x2407
UINT
100
0
6000
rpm
RW
9224
0x2408
BRAKE Output Delay
Time
0x2408
UINT
100
0
1000
ms
RW
9225
0x2409
Torque Limit at
Homing Using Stopper
0x2409
UINT
250
0
2000
0.10%
RW
9226
0x240A
Duration Time at
Homing Using Stopper
0x240A
UINT
50
0
1000
ms
RW
9227
0x240B
Modulo Mode
0x240B
UINT
0
0
3
-
RW
9228
0x240C
Modulo Factor
0x240C
DINT
3600
1
0x3FF
FFFFF
UU
RW
9230
0x240E
User Drive Name
0x240D
STRING
Drive
UU
RW
9283
0x2416
Individual Parameter
Store
0x240E
DINT
0
0
1
-
RW
