Parker Hannifin

P series User Guide 91

0x2216

Digital Output Signal 4

Selection

UINT

0x2217

Digital Output Signal 4

Selection

UINT

Table 57. Allocating Digital Output Related Objects

You can set the output signal level by allocating functions of digital output signals of I/O

connector. Choose the signals to allocate with bit 7~0, and set the signal level at bit 15.

Bit

Details

Signal output level setting

(0:CONTACT A, 1:CONTACT B)

14~8

Reserved

7~0

Allocated output signal

Set

Value

Allocatable Output

Signals

0x00

Not Allocated

0x01

BRAKE

0x02

ALARM

0x03

RDY

0x04

ZSPD

0x05

INPOS1

0x06

TLMT

0x07

VLMT

0x08

INSPD

0x09

WARN

0x0A

TGON

0x0B

INPOS2

0x10

ORG

0x11

EOS

0x12

IOUT0

0x13

IOUT1

0x14

IOUT2

0x15

IOUT3

0x16

IOUT4

0x17

IOUT5
